Digital Programmable Multi Event Thermostat

Call or send email for more information and pricing.
Distributors and OEM orders welcome. We make clocks and displays to your specifications.

Jumbo LED Digital Clocks with REMOTE CONTROL

SELENA

SELENA Clock with Programmable Multi Event Thermostat

The thermostat program is retained in the internal, non-volatile memory and will remain intact even without power or backup battery.

OTHER PRODUCTS:
DIGITAL THERMOSTATS and TIMERS for SAUNA, SPA, POOLS and STEAM BATH (with remote probes)
DIGITAL THERMOSTATS (with remote probes)
HOME THERMOSTATS for HVAC and WATER HEATER with remote probes
TALKING THERMOSTATS for Visually Impaired and for convenience
DIGITAL DIFFERENTIAL THERMOSTATS for SOLAR HEATING and VENTILATION (with remote probes)
DIGITAL TIMERS for all uses including Motor/Pump cycling for Aquarium, Stoves, Heaters etc...

E-mail: sales@ledclocks.com

GO TO
INDEX

ORDERING
INSTRUCTIONS

List Of
Options

APPLICATIONS

HOSPITAL
SCHOOL
AIRPORT
MILITARY BASE
MARINE VESSELS
SHIPS, BOATS
SUBMARINES
BANK
STADIUM
GYM
CHURCH
SUBWAY STN.
BUS STN.
RAILWAY STN.

LED Clocks
and Timers

INDEX

E-mail: sales@ledclocks.com

Each Event Start Time is preset with 1 minute resolution.

1) Event Start Time

Option 1SPDT1PR :

Toll Free: 1-866-829-4253

All programming is done with the Hand Held Remote Control ( included ).
Each Event is programmed separately and consists of the following values :

The Mutli-Event Thermostat operates in the background and the Clock Time, Date, Weekday, Month and Year can be still displayed in any mode, as set-up by the user. The clock can be synchronized to any Master clock or can be set-up to be the Master for other Slave clocks.

2) Event Target Temperature

Each temperature is programmed with 1 deg. F ( or 1 deg. C ) resolution within the range from - 40F to +255F ( or - 40C to +124C ) .

NOTE:
The Mutli-Event Thermostat is NOT sensitive to the power interruptions. Even after the power absence for longer periods of time, the programmed schedule will be executed withour error, as if the power was present all the time.

3) Programming of Temperature Limits and Heat / Cool Auto Change-over

The thermostat may be programmed with temperature limits that will prevent oveheating or overcooling even if the target temperature is set outside the limits.

In the AUTO mode the automatic change-over temperature points may be programmed to switch automatically between the heating and cooling.

For the MANUAL mode the target temperature may be programmed in advance for fast override of the AUTO mode with the MANUAL mode.

Option # 713 :
For manually preset Heating Control and Alarm with 1 or 2 external probes.

Option # 714B :
For Heating or Cooling up to 32 events per day, separate for each of the 7 days of the week

Option # 714C :
For Heating and Cooling ( AC ) up to 32 events per day, separate for each of the 7 days of the week
and with Auto Change-Over for Heat / Cool

NOTES :
1) The Temperature Sensing probe wiring may be extended up to 500 feet ( 150 M ) with any type of a 2-conductor cable.
2) Terminal block on the back panel for wiring to the probes and to the internal relay contacts. Load up to 10 Amp, 250Vac.

1 Externally wired Probe
and 1 Internal SPDT relay
contacts for switching
of the Heating or Cooling System

WIRING OPTIONS:

Option 1SPDT2PR :

2 Externally wired Probes.
Either one may be selected for control and the other for monitoring only.
1 Internal SPDT relay contacts for switching
of the Heating or Cooling System

Temperature Range: - 40F to +255F ( - 40C to +144C )
Accuracy +/- 1F ( 0.5C ) .
Resolution 1F ( 1C ) for 4 digits and 0.1F ( 0.1C ) for 6 digits displays .
Selectable Celsius or Fahrenheit .
1 or 2 Externally wired probes up to 500 Ft ( 150 M ), no special cable required .
Temperature Display for 1 or 2 probes . For instance Inside and Outside .
Minimum and Maximum Temperature memory and display.
1 or 2 internal SPDT relays for control of heating and/or cooling ( or alarm ) .
Non-volatile program memory .
Self-reacharging backup for internal clock ( no batteries required ) .

FEATURES :

Option 2SPST1PR :

Option 2SPDT2PR :

1 Externally wired Probe
and 2 Internal SPST relays
contacts for switching
of the Heating or Cooling System

2 Externally wired Probes.
Either one may be selected for control and the other for monitoring only.
2 Internal SPDT relays contacts for switching
of the Heating or Cooling System

To Heating
or Cooling
System

To Heating
System

To Cooling
System

To Heating
or Cooling
System

NORMALLY
OPEN

NORMALLY
CLOSED

COM

To Heating
System

To Cooling
System

NORMALLY
CLOSED

NORMALLY
OPEN

COM

NORMALLY
OPEN

NORMALLY
CLOSED

TEMP
PROBE

TEMP
PROBE 1

TEMP
PROBE 2

TEMP
PROBE

WIRING
UP TO 500 FT
( 150 M )

TEMP
PROBE 1

TEMP
PROBE 2

Option 1SPDT1PR

Option 2SPDT2PR

Option 2SPST1PR

Option 1SPDT2PR

KERA Technologies Inc.

Temperature Probes and Sensors ( for options # 711, 712, 713, 714B and 714C )

The temperature monitoring, programmable thermostat and control options require an internal or external temperature sensor probe. The standard sensor normally included with the selected option may not be the most suitable model for each application and therefore a specific probe model may be ordered.
The selection below shows some of the available models and mounting accessories.
NOTE, that the probe wiring may be extended up to 500 ft ( 150 m ) with any type of a 2-conductor cable.
